Hikmicro M31 Professional Handheld Thermal Imaging Camera

Uncompromised 50Hz Fluidity and Next-Generation Thermal Sensitivity.

The HIKMICRO M31 is a premium, professional-grade handheld thermography camera that represents a major performance leap in the M-Series line. Equipped with a high-density 384 x 288 native thermal core, a fast 50Hz refresh rate, and an industry-leading thermal sensitivity (< 30 mK), the M31 is purpose-built for advanced electrical diagnostics, heavy mechanical asset inspections, and intensive building science applications. Its rugged pistol-grip form factor pairs with an ultra-bright 3.5" LCD touchscreen display to deliver rapid, exact temperature analyses under the most demanding site pressures.

Key Features:

• Flagship 384 x 288 Core with 50Hz Refresh Rate: Harnesses 110,592 native measurement pixels operating at a fluid 50Hz image frequency. This eliminates screen stuttering or motion blur while panning across complex breaker panels or high-speed machinery.

• Next-Gen SuperIR Up-Scaling: Onboard processing dynamically upsamples live video feeds and captured snapshots 4X onto the screen, outputting a highly detailed 768 x 576 display resolution for maximum target edge definition.

• Industry-Leading < 30 mK Thermal Sensitivity: An ultra-sensitive VOx detector captures microscopic thermal shifts down to fractions of a degree, making it exceptionally reliable at identifying faint moisture lines, insulation voids, or early-stage component resistance.

• Precision Manual Focus with Closer Macro Ability: The manual focus lens ring allows for crisp target focus from as close as 10 cm (0.32 ft) out to infinity. Paired with a continuous 1.0x to 8.0x digital zoom, technicians can safely isolate components from a distance or run detailed macro-level trace reviews.

• Expanded 650°C (1202°F) Industrial Range: Confidently reads high-temperature targets spanning from -20°C up to 650°C with an accuracy of ±2°C or ±2%. Features a 1-Tap Touchscreen Level & Span adjustment to instantly narrow image contrast over critical components.

• Versatile Image Blending & Measurement Tools: Offers 5 image modes including Thermal, Optical, Picture-in-Picture (PIP), Blending, and Bi-Spectrum Image Fusion, which integrates 8 MP visual camera edges cleanly onto heat patterns. Supports 10 customizable point spots, 1 line, 5 rectangles, and 5 circles for comprehensive on-screen radiometric metrics.

• Streamlined Multi-Annotation Reporting: Save up to 100,000 radiometric pictures or 300 hours of continuous MP4 video directly onto the included 64GB removable card. Tag captures on-the-fly via 60-second voice notes or 200-character on-screen text entries instead of wasting time with manual paperwork.

• Industrial IP54 Rugged Design: Features an IP54 dust and splash-proof shell built to easily withstand a 2-meter (6.56 ft) industrial drop test. Includes built-in Wi-Fi and Bluetooth to instantly beam inspections to your phone using the free HIKMICRO Viewer app.
